Key Features & Advantages
- 8,500 lumens color & white brightness – bright-room ready
- Native WUXGA + 4K Enhancement & HDR10 for cinema-grade images
- 20,000-hour sealed laser – zero maintenance, no filters
- Ultra-light 16 kg white body – seamless ceiling integration
- Compatible with 9 motorized lenses + extreme lens shift
NFC + built-in camera + EPPT app for 5-minute multi-projector setup
Best Applications
- Modern corporate boardrooms & training centers
- University classrooms & medium auditoriums
- Houses of worship with bright interiors
- Retail flagship stores & showroom displays
- Edge-blending & projection mapping in mid-size venues
The Epson CB-PU2010W is a reliable engineering-grade 3LCD laser projector, designed for large-scale application scenarios such as auditoriums, exhibition centers, command dispatch rooms, and cultural and artistic venues. It integrates stable laser light source, high brightness output, flexible installation and calibration capabilities, and long-term reliable operation performance. All parameters below are integrated from Epson official technical documents, authoritative projection testing platforms, and industry certification data, providing accurate and standardized reference for project planning and equipment selection.
Category | Subcategory | Specifications |
Basic Information | Model Name | CB-PU2010W (China Model); EB-PU2010W (Global Model) |
 | Product Type | Engineering-Grade 3LCD Laser Projector |
 | Projection System | 3LCD Technology (3-Chip RGB Liquid Crystal Shutter System) |
 | Dimensions (W×D×H) | 545×530×167 mm (without lens/feet); 545×550×200 mm (max size with feet installed) |
 | Weight | Approximately 16.0 kg (net weight, without lens) |
 | Operating Temperature | 0°C – 40°C; Operating Altitude: 0m – 2000m (High-Altitude Mode supported for areas above 1500m) |
 | Storage Temperature | -10°C – 60°C (relative humidity: 10%-90%, non-condensing) |
 | Warranty | 3-Year Standard Warranty for the whole machine; 20,000 hours maintenance-free warranty for laser light source (Standard Mode) |
Display Performance | Native Resolution | WUXGA (1920×1200), 2.304 million pixels |
 | Enhanced Technology | 4K Enhancement Technology, supporting 4K/60Hz input signal, realizing near-4K display effect |
 | Aspect Ratio | 16:10 (compatible with 4:3, 16:9, 21:9 via digital scaling) |
 | Color Reproduction | 10-bit color processing, up to 1.07 billion colors; 100% NTSC color gamut coverage |
 | Color Modes | Dynamic, Presentation, Cinema, Natural, HDR10, HLG |
 | HDR Support | Compliant with HDR10 and HLG standards, equipped with dynamic tone mapping technology |
 | Refresh Rate | 192Hz-240Hz, ensuring smooth display of dynamic images and video content |
Brightness & Contrast | White Light Output (ISO) | 10,000 lumens (Standard Mode); 7,000 lumens (Eco Mode) |
 | Color Light Output | 10,000 lumens (IDMS 15.4 certified, consistent with white light output) |
 | Dynamic Contrast Ratio | Over 10,000,000:1 (Dynamic Mode with auto aperture enabled) |
 | Brightness Adjustment | 50%-100% stepless adjustment, supporting Brightness Constant Mode to avoid lumen degradation |
Optical System | LCD Panel | 0.76-inch inorganic poly-silicon TFT active matrix panel |
 | Light Source | High-power laser diode array + reflective fluorescent wheel |
 | Light Source Life | 20,000 hours (Standard Mode); 30,000 hours (Eco Mode), maintenance-free |
 | Cooling System | Dual-channel efficient thermal management system, supporting 24/7 continuous operation |
Lens Specifications | Lens Type | Interchangeable manual zoom/focus lens (multiple optional lenses for different scenarios) |
 | Standard Focal Length | 24.0mm-38.4mm (standard matching lens) |
 | Zoom Ratio | 1.0-1.6x (optical zoom, standard lens) |
 | Throw Ratio | 1.5:1-2.4:1 (standard lens, adaptable to different projection distances) |
 | Lens Shift Range | Vertical: -50% to +50%; Horizontal: -30% to +30% (manual adjustment) |
 | Projection Size | 60″-1000″ (diagonal, varies with optional lenses) |
Installation & Calibration | Projection Methods | Front, rear, ceiling, floor mounting; 360° free-angle installation (no brightness loss) |
 | Calibration Features | Supports auto color/geometry calibration (with optional ELPEC01 camera); professional edge blending |
 | Geometric Correction | Vertical ±40°, Horizontal ±40° (manual digital correction) |
 | Special Modes | Multi-projector stacking, curved screen projection, up to 15 units edge blending |
Connectivity | Digital Interfaces | HDMI 2.0 (HDCP 2.3) ×2; HDBaseT ×1 (supports 100m long-distance transmission) |
 | Network Interfaces | RJ45 (Gigabit LAN) ×1; optional Wi-Fi 6 (IEEE 802.11ax) module |
 | USB Interfaces | USB Type-A ×2 (5V/2A power supply); USB Type-B ×1 (service and maintenance) |
 | Audio Interfaces | 20W built-in dual speakers; stereo audio input/output |
 | Control Interfaces | RS-232C (D-Sub 9-pin) ×1; PJLink; SNMP; web-based control; Crestron compatible |
Power & Operation | Power Supply | AC 100-240V ±10%, 50/60Hz |
 | Power Consumption | 700W (Standard Mode); 490W (Eco Mode) |
 | Standby Power Consumption | 2.0W (Network Standby); 0.5W (Eco Standby) |
 | Noise Level | 38dB (Standard Mode); 30dB (Eco Mode) |
 | Startup Time | ≤15 seconds (Quick Power-On Mode); supports instant cooling |
