Key Features & Advantages
- 5,000 lumens color/white brightness – sharp visuals in lit compact spaces
- Native WUXGA + 4K Enhancement & HDR for immersive detail
- 30,000-hour sealed laser – zero maintenance, energy-efficient operation
- Short-throw 0.5–0.7:1 + 1.4x zoom & wide lens shift for flexible setups
- HDBaseT, Wi-Fi 6, 10W speaker, split-screen & edge blending tools
- Optional PixAlign camera + NFC for auto-calibration & quick stacking
Best Applications
- Interactive classrooms & university lecture halls
- Corporate boardrooms & training rooms
- Museum exhibits & immersive displays
- Simulation setups & golf simulators
- Houses of worship & retail showrooms
The Epson CB-L590SE is an entry-level cost-effective 3LCD laser projector specifically designed for basic educational scenarios, such as primary school classrooms, rural teaching sites, community training centers, and small-scale vocational skill training rooms. It adheres to Epson’s consistent 3LCD color reproduction advantage and maintenance-free laser light source design, focusing on stability, ease of operation and cost-effectiveness to meet the basic needs of daily teaching, such as courseware display, picture demonstration and simple video playback. All parameters are sourced from Epson official technical documents and industry authoritative verification, providing accurate and accessible reference for educational institutions’ procurement, front-line teachers’ use and equipment management personnel’s maintenance.
Category | Subcategory | Specifications |
Basic Information | Model Name | CB-L590SE (China Model); EB-L590SE (Global Model) |
 | Product Type | Entry-Level Cost-Effective 3LCD Laser Projector for Basic Education |
 | Projection System | 3LCD Technology (3-Chip RGB Liquid Crystal Shutter System) |
 | Dimensions (W×D×H) | 365×265×108 mm (without lens/feet); 365×280×125 mm (max with feet installed) |
 | Weight | Approx. 4.8 kg (net weight, without lens) |
 | Operating Temperature | 0°C – 45°C; Operating Altitude: 0m – 3048m (High-Altitude Mode for >1500m) |
 | Warranty | 3-Year Whole Machine Warranty; 20,000hrs Laser Source Warranty (Standard Mode) |
Display Performance | Native Resolution | WUXGA (1920×1200), 2.304 million pixels |
 | Enhanced Technology | 4K Signal Acceptance, supports 4K/60Hz input signal |
 | Aspect Ratio | 16:10 (compatible with 4:3/16:9 via digital scaling) |
 | Color Reproduction | 10-bit color processing, up to 1.07 billion colors; 85% NTSC gamut |
 | Color Modes | Dynamic, Presentation, Cinema, Natural |
Brightness & Contrast | White Light Output (ISO) | 5,000 lumens (Standard); 3,500 lumens (Eco) |
 | Color Light Output | 5,000 lumens (IDMS 15.4 certified) |
 | Dynamic Contrast | Over 1,500,000:1 (Dynamic Mode, Auto Aperture On) |
Optical System | LCD Panel | 0.67-inch inorganic poly-silicon TFT active matrix |
 | Light Source | Laser diode array + reflective fluorescent wheel |
 | Light Source Life | 20,000hrs (Standard); 30,000hrs (Eco), maintenance-free |
Lens & Installation | Lens Type | Manual zoom/focus lens (center-aligned) |
 | Zoom Ratio | 1.1-1.3x (optical) |
 | Lens Shift | Vertical: -15%~+15%; Horizontal: -5%~+5% (manual) |
 | Projection Size | 30″-180″ (diagonal); Projection Distance: 0.8m-5.5m |
 | Installation Modes | Front/Rear/Ceiling/Floor; 360° free-angle installation |
Connectivity | Digital Interfaces | HDMI 2.0 (HDCP 2.3)×2 |
 | Network | RJ45 (Gigabit)×1; Built-in Wi-Fi 5 (IEEE 802.11ac) |
 | Control | RS-232C×1; Web-based control |
Power & Operation | Power Supply | AC 100-240V±10%, 50/60Hz |
 | Power Consumption | 260W (Standard); 182W (Eco) |
 | Noise Level | 32dB (Standard); 22dB (Eco) |
 | Startup Time | ≤13 seconds; supports instant cooling |
